Application Charts (85 HP - 100 HP)

Johnson Evinrude Application Charts
HP Model Year Cyl. Ign. Pack Stator Rec/Reg Trigger Harness Ign. Coil
85 TTL W/Trim 94 4 113-4030 173-3536 193-4204 133-3379 413-4390 186-2508
85 TTL 95 4 113-4028 173-3536 193-4204 133-3379 R584356* 186-2508
88 W/O Trim 89-91 4 113-4028 173-3536 153-3408 133-3379 413-4004 186-2508
88 W/Trim 89-91 4 113-4028 173-3536 193-4204 133-3379 413-4004 186-2508
88 92-93 4 113-4028 173-3536 153-3408 133-3379 R584389* 186-2508
88 W/O Trim 94 4 113-4030 173-3536 153-3408 133-3379 R584389* 186-2508
88 W/Trim 94 4 113-4030 173-3536 193-4204 133-3379 R584389* 186-2508
88 TS W/20 IN 94-95 4 113-4028 173-3536 153-3408 133-3379 R584389* 186-2508
88 TS W/25 IN 94-95 4 113-4028 173-3536 193-4204 133-3379 413-4390 186-2508
88 MS 95 4 113-4028 173-3536 153-3408 133-3379 R584389* 186-2508
88 MS 96 4 113-4028 173-3536 153-3408 133-3379 R584389* 186-2508
88 TS W/20 IN 96 4 113-4028 173-3536 153-3408 133-3379 413-6027 186-2508
88 TS W/25 IN 96 4 113-4028 173-3536 193-4204 133-3379 413-6027 186-2508
90 6 Amp 84 4 113-2125 173-3672 153-3408 133-3376 413-4495 186-2508
90 10 Amp 84 4 113-2125 173-3672 193-5204 133-3376 413-4495 186-2508
90 W/O Trim 85 4 113-2811 173-3672 153-3408 133-3376 413-4495 186-2508
90 W/Trim 85 4 113-2811 173-3672 193-5204 133-3376 413-4495 186-2508
90 W/O Trim 86-87 4 113-3110 173-3672 153-3408 133-3376 413-3036 186-2508
90 W/Trim 86-87 4 113-3110 173-3672 193-5204 133-3376 413-3036 186-2508
90 W/O Trim 89-90 4 113-4028 173-3536 153-3408 133-3379 413-4004 186-2508
90 W/Trim 89-90 4 113-4028 173-3536 193-4204 133-3379 413-4004 186-2508
90 91 4 113-4028 173-3536 193-4204 133-3379 R584211* 186-2508
90 W/O Trim 94 4 113-4030 173-3536 153-3408 133-3379 413-4390 186-2508
90 W/Trim 94 4 113-4030 173-3536 193-4204 133-3379 413-4390 186-2508
90 JE TurboJet 94 4 113-4030 173-3536 193-4204 133-3379 413-4390 186-2508
90 TurboJet 95 4 113-4030 173-3536 193-4204 133-3379 413-4390 186-2508
90 EL/EX/ 60 Deg 95 4 R586292* 173-4849 193-6048 133-6343 413-5085 183-3740
90 60 Deg 96 4 R586292* 173-4849 193-6048 133-6343 413-4762 183-2382
90 60 Deg 97-00 4 R586292* 173-4849 193-6048 133-6343 413-4762 183-2382
100 65-66 4 N/A ** R380076 POINTS 413-9900 183-2508
100 Starflite 67 4 113-8362 R580648* 153-3408 R580668* 413-9908 183-2508
100 Starflite 68 4 113-8362 R580725* 153-3408 133-5008 413-9909 183-2508
100 W/Alt 68 4 N/A ** N/A
* Premier Services Availability Only ** Part Currently Unavailable by CDI Electronics at this time (a) Engines with Option 35 Amp Upgrade ***May Require Mounting Modification
