Timer Bases & Rectifiers

Johnson Evinrude
Maintenance Free, AGM and Gel
Cell Batteries
were not designed to work with any
Rectifier, Regulator, etc. and may not
allow accurate sense of the battery
voltage/charge, resulting in damage to
your battery and ignition parts.
Rectifiers
Fits: 1970-1972 (100, 115, &
125 HP)
Replaces: 382534, 384461, 385008
* Companion to 113-8362
Timer Base Rotor
4 Cylinder
Fits: 1967-1968 (Engines with
Belt Driven Distributor)
Replaces: 510705
Timer Base Sensor
3/4 Cylinder
Fits: 1992-2005 (40 & 50 HP -
Engines using a 3 wire
trigger)
Replaces: 175386, 763808
Timer Base
2 Cylinder
Trigger Sensor
4 /6 Cylinder
Fits: 1991-2006 (150-175 HP -
6 Cyl.)
1994-2006 (90-115 HP - 4
Cyl. - 60 Degree Optical (OIS
2000 - Carbureted Engines)
Replaces: 584265, 584914, 586343
Rectifier
Fits: 1967 (60, 80 HP)
Replaces: 580656
*3 wire rectifier replacement.
*Do Not Use Maintenance
Free Battery.
Over-Voltage Will Occur
Rectifier
3 & 4 Cylinder
Fits: 1968 (85-100 HP - 4 Cyl.)
1969 (55 & 65 HP - 3 Cyl.)
Replaces: 580698, 580705, 580771
*3 wire rectifier replacement.
*Do Not Use Maintenance Free
Battery.
Over-Voltage Will Occur
Upgrade
Available
Get Better Performance with
a Regulated Rectifier. See
193-0656 on Page 62.
Upgrade
Available
Get Better Performance with
a Regulated Rectifier. See
193-0705 on Page 62.
Johnson Evinrude
Timer Bases
56
16
2015
