Application Charts (150 HP - 300 HP)

Mercury, Mariner Application Charts
Application ChartsMercury, Mariner
HP Model Cyl. Year Serial Number Switch Box Stator Trigger Rec./Reg. Harness
150 16 Amp 6 90-91 0C239553-0D081999 114-7778 174-5456-16 134-6456 154-8825K 1 (g) 414-6220A 4
150 40 Amp 6 90-91 0C239553-0D081999 114-7778 174-9610K 2 134-6456 194-1873 (f) 414-6220A12
150 40 Ano 6 92-95 0D082000-0G303045 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
150 2 Stk. 6 96-99 0G303046-0G960499 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
150 3 Stk. 6 00-05 0G960500-0T408999 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
175 Black Max 6 76-79 4301235-5593736 114-7778 174-5456 134-6456 154-6770 414-6220A 4
175 Black Max 6 79-84 5593737-6618750 114-7778 174-5456 134-6456 154-6770 414-6220A 4
175 9 Amp 6 85-88 6618751-0C100860 114-7778 174-5456 134-6456 154-6770 414-6220A 4
175 15 Amp 6 85-88 6618751-0C100860 114-7778 174-5456-16 134-6456 154-8825K 1 (g) 414-6220A 4
175 40 Amp 6 89-90 0C100861-0C239552 114-7778 174-9610K 2 134-6456 194-1873 (f) 414-6220A12
175 16 Amp 6 90-91 0C239553-0D081999 114-7778 174-5456-16 134-6456 154-8825K 1 414-6220A 4
175 40 Amp 6 90-91 0C239553-0D081999 114-7778 174-9610K 2 134-6456 194-1873 (f) 414-6220A12
175 Xri EFI 6 92-95 0D082000-0G303045 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
175 Xri EFI 6 96-00 0G303046-0G840500 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
175 2 Stk. 6 96-99 0G303046-0G960499 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
175 3 Stk. 6 00-05 0G960500-0T408999 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
175 XR2 Sp. Jet 6 97-05 0E151580-0E433133 114-4953-32 174-9873-16 134-6456-15 194-5279 R84-832102A 2*
200 Black Max 6 78-79 4839034-5363917 114-7778 174-5456 134-6456 154-6770 414-6220A 4
200 Black Max 6 79-81 5363918-6073191 114-7778 174-5456 134-6456 154-6770 R84-87266A1*
200 15 Amp 6 82-90 6073192-0C239553 114-7778 174-5456-16 134-6456 194-8825K 1(g) 414-6220A 4
200 16 Amp 6 85-90 6625221-0C239553 114-7778 174-5456-16 134-6456 194-8825K 1(g) 414-6220A 4
200 Xri 40 Amp 6 89-91 0C100861-0G303045 114-7778 174-9610K 2 134-6456 194-1873 (f) 414-6220A 12
200 16 Amp 6 89-91 0D082000-0G201874 114-7778 174-5456-16 134-6456 194-8825K 1 414-6220A16
200 40 Amp 6 89-91 0G201875-0G30345 114-7778 174-9610K 2 134-6456 194-1873(f) R84-826730A 4*
200 2 Stk. 6 92-00 0G303046-0G960499 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
200 2 Stk. 6 00-05 0G960500-1B226999 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
200 2.5L EFI 6 92-99 0D082000-0G840500 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
200 EFI 6 00-05 0G960500-0T408999 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
210 Sp Jet 6 97-99 0E370318-0E433133 114-4953-32 174-9873-16 134-6456-15 194-5279 R84-832102A 2*
220 - 6 87-88 0B117316-0C100860 114-7778 174-5456-16 134-6456 194-8825K 1(g) R84-92432A 6*
225 - 6 81-93 5628028-0D280812 114-7778 174-5456-16 134-6456 194-8825K 1 -
225 2.5L EFI 6 95-00 0D935638-0G569900 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
225 3.0L 6 93-94 0D280813-0G129221 114-7509K1 R821935A 3* - Alternator R84-825433A 7*
225 3.0L 6 94-95 0G129222-0G303045 114-7509K1 R821935A 5* - Alternator -
225 3.0L 6 96-01 0G303046-0T408999 114-7509 R821935A 5* - Alternator -
240 Sp Jet 6 00-05 0E373939-0E406399 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-877614A 2*
250 3.0L 6 94-95 0G129222-0G303045 114-7509K1 R821935A 5* - Alternator -
250 3.0L 6 96-00 0G303046-0G840500 114-7509 R821935A 5* - Alternator -
250 XB 3.0L 6 00-02 0G980600-0T408999 114-7509 R821935A 5* - Alternator R84-825433A11*
300 ProMax 6 98-01 0G980600-0T408999 114-7509 R821935A 5* - Alternator R84-825433A11*
*Premier Services Availability Only **Part Currently Unavailable by CDI Electronics at this time (a) Use 994-4463 (b) Auxillary Charging Stator is Premier Services Only (c) If Linkage 90 Deg., Order 134-6454
(d) If Linkage Straight, Order 134-6452 (e) Order 114-2986K 1 if original had 337-4406 (f) Order 194-1873 if Stator has 2 Yellow Wires (g) Replaces both Rectifier & Regulator
