Application Charts (40 HP - 60 HP)

Mercury, Mariner Application Charts
HP Model Cyl. Year Serial Number Switch Box Stator Trigger Rec./Reg. Harness
40 Elec Str. 2 81-84 5823918-6052942 114-7452A3 174-6617K 1 R92431A1* 154-6770 414-6219A 2
40 Elec Str. 2 81-84 6052943-6999999 114-7452A3 174-6617K 1 R92431A1* 154-6770 414-6219A 2
40 Man. Str. 2 81-84 5823918-6999999 114-7452A3 174-6617K 1 R92431A1* - -
40 Elec Str. 4 89-91 C159200-D055047 114-5772 174-9710K 1 134-6452(c) 194-5279 414-8672
40 Man. Str. 4 89-91 C159200-D055048 114-5772 174-8778K 1 134-6452(c) - -
40 Elec Str. 4 91-97 D055048-OG589999 114-5772 174-9710K 1 134-6452(c) 194-5279 414-8672
40 Elec Str. 2 95-96 0G055314-0G380074 114-7509K 1
40 Man. Str. 2 95-96 0G055314-0G380074 114-7509K 1
40 Elec Str. 2 96-99 0G380075-0G589999 114-7509
40 Man. Str. 2 96-99 0G380075-0G589999 114-7509
174-2075K 1 134-9021-2 - R84-854323A 2*
40 Elec Str. 2 00-05 0G590000-0T999999 114-7509 174-2075K 2 134-3960-2 194-5279 R84-854322A 2*
40 Man. Str. 2 00-05 0G590000-0T999999 114-7509 174-2075K 1 134-3960-2 - R84-854323A 2*
40 Elec Str. 3 97-05 0G590000-0T999999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
40 Man. Str. 3 97-05 0G590000-0T999999 114-7509 174-2075K 1 134-4512-3 - -
40 Elec Str. 4 Stk 3 02-05 0T178500-1B344298 **87843302S 174-2387 - 194-2115K 1 R84-854322A 2*
40 Man. Str. 4 Stk 3 02-05 0T178500-1B344298 **87843302S 174-2386 - - R84-854323A 2*
40 Elec Str. 4 Stk 4 02-05 0T178500-0T598999 **878433A 3 174-2387 - 194-2115K 1 R84-857111T 2*
40 Jet 4 89-97 C159200-0G589999 114-5772 174-5454K 1 134-6452(c) 154-6770 414-8672
40 Jet 3 98-01 0G590000-0T408999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
40 Jet Elec Str. 3 02-05 0T178500-0T979999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
40 Jet Man Str. 3 02-05 0T178500-0T979999 114-7509 R398-832074A 5* 134-4512-3 - -
45 Elec Str. 4 81-89 5531630-B393190 114-5772 174-5454K 1 134-6452(c) 154-6770 414-6277
45 Man.Start 4 81-89 5531630-B393190 114-5772 R76314A3 134-6452(c) - -
45 Jet 3 91-99 D000750-OG589999 114-9052 174-9710K 1 134-9021-3 194-5279 414-9061
50 500 4 67 2116318-2305100 114-2986 R398-2996 R393-2918A1* 154-6770 414-2770
50 Elec Str. 4 70-75 2858814-4357639 R333-3213* 174-3175 (Red)
174-3176 (Blue)
IGN DRIVER 154-6770 414-2770
50 Elec Str. 4 76-79 4357640-5531629 114-5772 174-5454K 1 134-6452(c) 154-6770 414-3369
50 Man. Str. 4 76-79 4357640-5531629 114-5772 R76314A3* 134-6452(c) - -
50 Elec Str. 4 80-85 5531630-A912477 114-5772 174-5454K 1 134-6452(c) 154-6770 414-6277
50 Man. Str. 4 80-85 5531630-A912477 114-5772 R76314A3* 134-6452(c) - -
50 - 3 84-90 6428681-D000749 114-7778 174-5454K 1 134-6453 154-6770 414-4614
50 - 3 91-97 D000750-OG589999 114-9052 174-9710K 1 134-9021-3 194-5279 414-9061
50 Man. Str. 3 97-06 OG531301-OT999999 114-7509 R398-832074A 5* 134-4512-3 - -
50 Elec Str. 3 97-06 OG531301-OT999999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
50 Jet 3 98-05 0G590000-0T408999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
50 Elec Str. 4 Stk 4 02-05 0T178500-0T598999 **878433A 3 174-2387 - 194-2115K 1 R84-857111T*
50 EFI 4 Stk 4 2005 0T409000-0T800999 - R398-878143T 3* - 194-2115K 1 R84-877804T 3*
50 EFI 4 Stk 4 2006 0T801000-1B344306 - R398-878143T05* - 194-2115K 1 -
50 EFI 4 Stk 4 06-07 1B344306-1C050252
- R398-878143T05* - 194-2115K 1 -
55 Elec Str. 3 92-97 0D000750-OG589999 114-9052 174-9710K 1 134-9021-3 194-5279 414-9061
55 Man.Start 3 96-97 0G290585-OG589999 114-9052 R398-832074A 5* 134-9021-3 - -
55 Elec Str. 3 98-07 0G590000-OT980000 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
60 - 3 84-90 6428681-D000749 114-7778 174-5454K 1 134-6453 154-6770 414-4614
*Premier Services Availability Only **Part Currently Unavailable by CDI Electronics at this time (a) Use 994-4463 (b) Auxillary Charging Stator is Premier Services Only (c) If Linkage 90 Deg., Order 134-
6454 (d) If Linkage Straight, Order 134-6452 (e) Order 114-2986K 1 if original had 337-4406 (f) Order 194-1873 if Stator has 2 Yellow Wires (g) Replaces both Rectifier & Regulator
TECH SUPPORT: 1.866.423.4832 CALL TO ORDER: 1.800.209.9624
